PULSAR H - Hybrid Single Solenoid HPA Engine
Experience enhanced precision and alignment tolerance with the PULSAR H's innovative 2-stage hybrid open-bolt system. This engine combines the advantages of both single and dual solenoid systems, eliminating common issues associated with traditional open-bolt designs while maintaining user-friendly operation and a lower cost typical of single solenoid engines. The nozzle movement cycle is separated from the air supply cycle, ensuring consistent performance. Enjoy the benefits of an open-bolt system, including the elimination of the first-shot blank found in closed-bolt engines. Get insane muzzle velocities ranging from 250-550 FPS & ROF from 1-40 RPS for CQB, assault, and sniper replicas.
When purchased in a bundle with ASTER II Bluetooth®, you get an unprecedented trigger response, thanks to the combination of optical sensors and HPA technology. ASTER II Bluetooth® raises the price-performance ratio by including an adjustable Quantum Trigger 2 and Bluetooth® 5.2 onboard. Now, out of the box, you can set sensitivity from ludicrous touch through hair to full movement.
GCS App (GATE CONTROL STATION) gives you total control of your replica. It is a free universal app for configuring, controlling, and connecting the GATE Ecosystem elements such as the TITAN and ASTER Electronic Trigger Units or the tactical computer STATUS. The app is compatible with Android, iOS, Wear OS, watchOS, Windows, and macOS devices.
PULSAR H FEATURES: PULSAR H is unique thanks to the following combination: Innovative 2-stage hybrid open-bolt system Enhanced precision and alignment tolerance It is definitely less sensitive to replica and assembly quality It combines the advantages of both single and dual solenoid systems, eliminating common issues associated with traditional open-bolt designs while maintaining user-friendly operation and a lower cost typical of single solenoid engines Separated nozzle movement cycle from the air supply cycle, ensuring consistent performance No first-shot blank found in closed-bolt engines Seamless integration & compatibility with the most advanced optical ETU/FCU TITAN II Bluetooth® & ASTER II Bluetooth® for a synergy eff High tolerances eliminating the mid-cap syndrome No FPS drops on AUTO relative to SEMI mode at high RPS – up to 40 RPS with no FPS dropsSIMPLE – Easy maintenance, thanks to a well thought-out design
VALUE FOR MONEY – State-of-the-art technology at the best price
Bluetooth® ETU/FCU CONTROLLED – ASTER II Bluetooth® V2
NO MID-CAP SYNDROME - Eliminated mid-cap syndrome thanks to high dimensional tolerance
ACCURACY – High accuracy due to the innovative 2-stage hybrid open-bolt system
STABILITY – FPS stability in full AUTO mode
ACCESSORIES – Use the I/O port to connect accessories such as the bolt-catch button, magazine sensor
SPECIFICATIONS:
PULSAR H – Hybrid Single Solenoid HPA Engine
The design and production of the device is based on harmonized standards.
Solenoid Voltage Range: 5-8.4 V
Operating Pressure: Up to 140 PSI – high pressure only
Gas Consumption: For 90 PSI and a 48 ci/0.8 l 300 bar/4500 PSI bottle – 1 PSI per shot
Dimensions (Length x Diameter): 116 mm x 25.4 mm
Finished Product Weight: 92 g
Operating Temperature Range: min. -15° C, max. +50° C
Relative Humidity: ≤ 80%
Regulated ROF: 1 to 40 RPS (BB feed correctness depends on magazine)
Velocity: 250 – 550 FPS
Operation Mode: Hybrid Open-Bolt
